Multiple US and international patent applications cover various aspects of our innovative technology and implementations. Our issued US patents include:​

US Patent 9,240,791

Clock Distribution Architecture for Logic Tiles of an Integrated Circuit and Method of Operation Thereof

US Patent 9,496,876

Clock Distribution Architecture for Logic Tiles of an Integrated Circuit and Method of Operation Thereof

US Patent 9,503,092

Mixed-Radix and/or Mixed-Mode Switch Matrix Architecture and Integrated Circuit, and Method of Operating Same

US Patent 9,543,958

Multiplexer-Memory Cell Circuit, Layout Thereof and Method Manufacturing Same

US Patent 9,755,651

Multiplexer-Memory Cell Circuit, Layout Thereof and Method of Manufacturing Same

US Patent 9,786,361

Programmable Decoupling Capacitance of Configurable Logic Circuitry and Method of Operating Same

US Patent 9,793,898

Mixed-Radix and/or Mixed-Mode Switch Matrix Architecture and Integrated Circuit, and Method of Operating Same

US Patent 9,817,933

Network Architectures for Boundary-less Hierarchical Interconnects (this is a patent with inventors Cheng Wang and Dejan Markovic based on their work while at UCLA, before Flex Logix; Flex Logix is the exclusive licensee)

US Patent 9,882,568

Clock Distribution Architecture for Logic Tiles of an Integrated Circuit and Method of Operation Thereof

US Patent 9,906,225

Integrated Circuit Including an Array of Logic Tiles, Each Logic Tile Including a Configurable Interconnect Network.

US Patent 9,923,555

Fine-grained Power Gating in FPGA Interconnects. (this is a patent with inventors Cheng Wang and Dejan Markovic based on their work while at UCLA, before Flex Logix; Flex Logix is the exclusive licensee)

US Patent 9,941,887

Multiplexer-memory Cell Circuit, Layout Thereof and Method of Manufacturing Same

US Patent 10,348,308

Clock Architecture, including Clock Mesh Fabric, for FPGA, and Method of Operating Same

US Patent 10,411,711

FPGA having a virtual array of logic tiles, and method of configuring and operating same

US Patent 10,411,712

FPGA having programmable powered-up/powered-down logic tiles, and method of configuring and operating same

Patents in other countries are not listed here. Numerous additional patent applications are in process in the USA and other countries.

Awards

Awards

  • 2017 - TSMC Partner of Year Award
  • 2015 - ISSCC Outstanding Paper Award
  • 2014 - ISSCC Award outstanding paper
2017 09 TSMC Partner of Year Award from Cliff Hou -- Awards-0013

Technology

Flex Logix™ Technology

Superior Interconnect

Inference and eFPGA are both data flow architectures. A single inference layer can take over a billion multiply-accumulates. Flex Logix directly connects the compute and RAM resources into a data path, like an ASIC; then repeats this layer by layer. Flex Logix utilizes a new breakthrough interconnect architecture: less than half the silicon area of traditional mesh interconnect, fewer metal layers, higher utilization and higher performance. The ISSCC 2014 paper detailing this technology won the ISSCC Lewis Winner Award for Outstanding Paper. The interconnect continues to be improved resulting in new patents.

Superior Scalability

We can easily scale up our Inference and eFPGA architectures to deliver compute capacity of any size. Flex Logix does this using a patented tiling architecture with interconnects at the edge of the tiles that automatically form a larger array of any size.

TIGHTLY COUPLED SRAM AND COMPUTE

SRAM closely couples with our compute tiles using another patented interconnect. Inference efficiency is achieved by closing coupling local SRAM with compute which is 100x more energy efficient than DRAM bandwidth. This interconnect is also useful for many eFPGA applications.

Superior Software

Our eFPGA compiler has been in use by dozens of customers for several years. Our inference compiler takes Tensorflow Lite and ONNX models to program our inference architecture using our eFPGA compiler in the back end. A performance modeler for our inference architecture is available now.

software driver

Software drivers will be available for common Server OS and real time OS for MCUs and FPGAs.

PCIe CARDS

Flex Logix chip products will be available in PCIe Card format for Edge Servers and Gateways. Other formats like U.2 or M.2 can be supplied as well.

Superior Low-Power Design Methodology

Flex Logix has numerous architecture and circuit design technologies to deliver the highest throughput at the lower power.
